Farm and field fence panels, also known as livestock panels or farm panels, are highly durable and versatile wire fences specifically designed for farms and ranches. These fences offer the ideal solution for containing and protecting livestock, as well as securing agricultural areas. With a variety of weave options available, including deer fence nets, fixed knot fences, hinged fences, square knot fences, diamond net fences, woven wire fences, and chain link fences, they provide a wide range of applications and features.
.png)
.png)
.png)
Farm fencing is also a kind of popular fence for fields or agriculture, also called farm fence or grassland fence,deer fence. It is woven by high tensile hot dipped galvanized with zinc coating above 200g/m2. It is a type of very economical fence for the farm, orchard, fields, grasslands, forest zone …etc. The formation of the field fencing is automatic twist plait by the line wire and the cross wire. So the fencing mesh is knotted. And the spacing between the line wire is different, smaller spacing in the bottom of mesh panel, then the spacing become much more bigger than the the bottom one. To design like that is to protect the little rodents or animals from getting through.
Farm fence can be woven with different types of knots: fixed knots, hinge joint knots or other custom patterns.
Hinge joint fence is a kind of fence, whose top and bottom wires are made of 2.5mm diameter wire, and the tensile strength is greater than or equal to 710N/mm2. The other wires are made of 1.9mm diameter wire, and the tensile strength is 440-540N/mm2.
Fixed knot fencing is a kind of fencing, usually made of high-strength galvanized steel wire. The wire is knitted into a grid-like structure through a special knitting machine, and then fixed and supported by a steel frame. It is widely used in stadiums, squares, playgrounds, amusement parks and other places.
The farm fencing post is to use the angle steel, to make holes on the angle steel, which is used to tie the fence panel with the post. And it can use the wooden stake to replace the angle steel. To fix the post and the fence panel together is using the galvanized wire.
All in all, the formation of the field fencing is not complex, and it is also very economical and save the production cost. It is a quite good choice to choose the field fencing.
Agricultural fence (such as horse fencing, livestock panel fence);
Ranch fence (such as sheep fencing, goat fence, deer fence and cattle fence);
Grassland fence (such as border fence).
Farm, Field fence has many widely range uses almost covering each corners in our lives. Field fences are mainly used for barriers in ranch construction, grazing and feeding of animals in agriculture farm and grassland fence;
Used for protection of natural environment.
Hinge joint farm fence
Materials: zinc-aluminium alloy wire (Galfan wire) or galvanized steel wire, both high tensile wire.
| Hinge Joint Field fence (cm) | 100/8/15 | 130/11/15 | 160/15/15 | 200/25/15 | 200/17/15 | ||
| Height (cm) | 100 | 130 | 160 | 200 | 200 | ||
| Horizontal wires number | 8 | 11 | 15 | 25 | 17 | ||
| Roll Length (m) | 50 | 50 | 50 | 50 | 50 | ||
|
Ø wire 2.5mm; Ø top and bottom wire 2.5mm |
mesh opening width (cm) | 15, 30 | 15, 30 | 15, 30 | 15, 30 | 15, 30 | |
| Roll weight (kg) | 17 | 26 | 35 | 52 | 40 | ||
|
Note: the following sizes also can be manufactured by your order : 200/22/15; 200/17/15; 180/24/15; 160/23/15; 150/13/15; 140/22/15; 140/11/15 |
|||||||
Fixed knot farm fence
Materials:zinc-aluminium alloy wire (Galfan wire) or galvanized steel wire ,both hightensile wire.
| Fixed knotted Field fence | |||||
| Item | Horizontal wire number | Inside wire gauge | Top & bottom wire gauge | Stay spacing | Fence height |
| FKF-1 | 23 | 12.5 | 10.5 | 3", 6" or 12" | 120" |
| FKF-2 | 20 | 12.5 | 10.5 | 3", 6" or 12" | 96" |
| FKF-3 | 17 | 12.5 | 10.5 | 3", 6" or 12" | 75" |
| FKF-4 | 15 | 12.5 | 10.5 | 3", 6" or 12" | 61" |
| FKF-5 | 13 | 12.5 | 10.5 | 3", 6" or 12" | 74" |
| FKF-6 | 13 | 12.5 | 12.5 | 3", 6" or 12" | 48" |
| FKF-7 | 9 | 12.5 | 12.5 | 3", 6" or 12" | 49" |
| FKF-8 | 16 | 12.5 | 12.5 | 3", 6" or 12" | 90" |
| FKF-9 | 14 | 12.5 | 12.5 | 3", 6" or 12" | 78" |
| FKF-10 | 10 | 12.5 | 12.5 | 3", 6" or 12" | 47" |
| FKF-11 | 17 | 12.5 | 12.5 | 3", 6" or 12" | 74" |
| FKF-12 | 13 | 12.5 | 12.5 | 3", 6" or 12" | 74" |
| FKF-13 | 11 | 12.5 | 12.5 | 3", 6" or 12" | 60" |
| FKF-14 | 8 | 12.5 | 12.5 | 3", 6" or 12" | 36" |
| FKF-15 | 8 | 12.5 | 12.5 | 3", 6" or 12" | 31" |
| FKF-16 | 7 | 12.5 | 12.5 | 3", 6" or 12" | 36" |
The higher carbon contents, the higher strength the fence wire will own. According the relative test, the high tensile fences are approximately twice the strength as low carbon field fence - that means they are stronger with a longer lifespan.
Need fewer postHigh tensile fence features higher breaking strength to be installed with bigger post spacing up to 16.5 feet, while the post spacing of low carbon wire fence is about 8 to 10 feet. So there are fewer fence posts are needed.
Low maintenanceOnce installed properly, only low even free maintenance is needed – that is because high tensile fences are not easy to sag and always retains tight over years, therefore there is no need of additional re-stretching.
Cost effectiveFewer posts and smaller diameters offer a big saving of cost and result in a competitive price. Additional, the high tensile fences are considered to be more safer to livestock, looks neater and easier to handle and install
Woven TypeThe field fencing is fully automatic machine production. The formation of the fence mesh is woven type. It is the twist plait by the line wire and the cross wire. It saved a lot of labor and reduce labor intensity. At last it made a flat surface, firm structure of the field fencing.
Simple StructureThe structure of the field fencing is very simple. So it has a very short production period and very easy to maintain. So with small size and light weight, it is convenient during the packing and loading on the container.
